NAS

NAS (Network Attached Storage) is a storage device that is connected to the network.
You can use part of the machine’s local drive area as a simple file server to save files and browse saved files.

FOLDER STRUCTURE

The folder structure is as follows.

  • root
    • public: Area for storing PDF files for PC browsing that have been created using the document filing function.
    • shared: Area where you can freely create folders.

    Saving files in NAS / browsing NAS files

    You can save data that you need to the machine’s local drive, and view the data on your computer.

    In document filing, tap the [Create PDF for PC Browsing] checkbox so that it is selected, and copy to the public folder to save the data.
    File Information

    Using as a file server / browsing saved files.

    To use this, open any folder screen on your computer and enter the IP address of the machine after "\\" in the address bar (example: \\192.168.1.28).
    • Access restrictions are set for each folder, so you must enter the login name and password of the administrator account or of a user account that has been registered in the machine.
    • The maximum size per file is 2 GB.
