Printed papers are
delivered to this tray.
This panel hosts
the [Power] button, Information indicator and touch panel.
Use the touch panel to operate each of these functions.
An NFC touch point area mark also appears.
This is used to connect
a USB device such as a USB memory device to the machine.
Supports USB 2.0 (Hi-Speed).
Use this tray to
feed paper manually.
When loading paper, also open the extension tray.
Grasp it when moving
the machine.
Store paper in this
tray.
Store paper in this
tray.
Store paper in this
tray.
Store paper in this
tray.
Open this cover to
replace a toner cartridge.
Heat is applied here
to fuse the transferred image onto the paper.
Warning
The fusing unit is hot. Take care not to burn yourself when removing a misfeed.During full colour
printing, the toner images of the four colours on the photoconductive
drums are combined together on the transfer belt.
During black and white printing, only the black
toner image is transferred onto the transfer belt.
Caution
Do not touch or damage the transfer belt.Connect the LAN cable
to this connector when the machine is used on a network.
Use a shielded LAN cable.
The machine does
not use this connector.
This is used to connect
a USB device such as a USB memory device to the machine.Supports
USB 2.0 (Hi-Speed) and USB3.0 (SuperSpeed).
This cartridge contains
toner.
When the toner in a cartridge runs out, replace
with new one.
This container collects
excess toner that remains after printing.
REPLACING THE TONER COLLECTION CONTAINER
Open this cover to
remove a paper misfeed.
And open when user changing the setting to print envelope.
Grasp it when moving
the machine.
This section describes the names and functions
of the respective parts of the operation panel.
This indicator illuminates
when the power to the machine is turned on, and when a user logs
in to the machine.
Messages and keys
appear on the touch panel display.
Operate the machine by directly tapping the displayed keys.
This indicator lights
up when the machine's power switch is on the position. Blinks blue
during the time that the [Power] button does not operate immediately
after the power plug is inserted into the power outlet.
Use this button to
turn the machine's power on and off.
You can easily connect
a mobile device to the machine by touching the mobile device.
Caution
When turning the machine power ON/OFF; at
user authentication when the user has logged in using IC card or
NFC; when connecting USB memory to the machine; when starting a
job on the machine control panel; or during image adjustment or
when adding toner; an error has occurred in the machine, the LED
lights blue and orange in response to the request/operation from
the user to communicate to the user the machine status.
Lighting patterns differ depending on status.
| Lighting colour | Lighting patterns | Status |
|---|---|---|
|
Blue |
Pattern 1 |
Job in progress, such as paper feeding or output. |
|
Pattern 2 |
Ready state or other state where jobs can be accepted. |
|
|
Orange |
Lights* |
Errors that do not stop machine operation, such as almost out of toner. |
|
Blinks* |
Errors that stop machine operation, such as misfeeds and out of toner. |
* If the lighting state and the blinking state overlap, the blinking state takes priority.
