Future-proof the way you work


Type Desktop
Engine speed A4*1 Max. 26 ppm
A3 Max. 15 ppm
SRA3 Max. 14 ppm
Control panel display 10.1-inch colour LCD touchscreen
Paper size Max. SRA3, min. A6*2
Paper capacity
(80 g/m2)
Standard 650 sheets
(550-sheet tray and 100-sheet bypass tray)
Maximum 6,300 sheets
(650 sheets & optional 550 + 2,100-sheet tray and 3,000-sheet tray)
Paper weight Tray 60 g/m2 to 300 g/m2
Bypass tray 55 g/m2 to 300 g/m2
Warm-up time*3 18 sec.*4
Memory Standard 5 GB (copy/print shared)    128 GB SSD*5
Option 512 GB *5*6
Power requirements Rated local AC voltage ±10%, 50/60 Hz
Power consumption Max. 1.84 kW (220 V to 240 V)
Dimensions (W x D x H)*7 609 x 662 x 860 mm
Weight (approx.) 84 kg


Original paper size Max.A3
First copy time*8 Colour 7.6 sec.
B/W 6.5 sec.
Continuous copy Max. 9,999 copies
Resolution Scan (colour) 600 x 600 dpi
Scan (B/W) 600 x 600 dpi, 600 x 400 dpi, 600 x 300 dpi*9
Print (colour) 600 x 600 dpi, 9,600 (equivalent) x 600 dpi (depending on copy mode)
Print (B/W) 1,200 x 1,200 dpi, 600 x 600 dpi,
9,600 (equivalent) x 600 dpi (depending on copy mode)
Gradation Equivalent to 256 levels
Zoom range 25% to 400% (25% to 200% using RSPF) in 1% increments
Preset copy ratios 10 ratios (5R/5E)


Scan method Push scan (via control panel), pull scan (TWAIN-compliant application)
Scan speed*10 Colour & B/W One-sided: Max. 120 originals/min.
Two-sided: Max. 240 originals/min.
Resolution Push scan 100, 150, 200, 300, 400, 600 dpi
Pull scan 75, 100, 150, 200, 300, 400, 600 dpi
50 dpi to 9,600 dpi via user setting*11
File formats TIFF, PDF, PDF/A-1a*12, PDF/A-1b, encrypted PDF, XPS, compact PDF*13 *14, JPEG*13, searchable PDF*12, OOXML (pptx, xlsx, docx)*12, text (TXT [UTF-8])*12, rich text (RTF)*12
Scan destinations Email/desktop*15/FTP server/network folder (SMB)/USB drive/local drive

Document Filing

Document filing capacity*16 Standard Main and custom folders: Max. 5,000 pages or 500 files
Quick file folder: Max. 5,000 pages or 500 files
Option Main and custom folders: Max. 20,000 pages or 3,000 files
Quick file folder: Max. 10,000 pages or 1,000 files
Stored jobs*17 Copy, print, scan, fax
Storage folders Quick file folder, main folder, custom folder (max. 1,000 folders)


Resolution 1,200 x 1,200 dpi, 600 x 600 dpi, 9,600 (equivalent) x 600 dpi
Interface USB 2.0 (host, high-speed), USB 3.0 (host, super speed), 10Base-T/100Base-TX/1000Base-T, wireless LAN (IEEE 802.11 a/b/g/n/ac)*18
Supported OS*19 Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022, Windows 8.1, Windows 10, Windows 11,
Mac OS 10.10, 10.11, 10.12, 10.13, 10.14, 10.15, 11, 12
Network protocols TCP/IP
Printing protocols LPR, Raw TCP (port 9100), POP3 (email printing), HTTP, FTP for downloading print files, IPP, IPP Everywhere, SMB,WSD
PDL Standard PCL 6 emulation
Option Adobe PostScript 3
Available fonts 80 fonts for PCL, 139 fonts for Adobe PostScript 3

Facsimile (requires optional BP-FX11)

Compression method MH/MR/MMR/JBIG
Communication protocol Super G3/G3
Transmission time Less than 3 seconds*20
Modem speed 33,600 bps to 2,400 bps with automatic fallback
Transmission resolution From Standard (203.2 x 97.8 dpi) to Ultra Fine (406.4 x 391 dpi)
Recording size A3 to A5
Memory 4 GB (built-in)
Greyscale levels Equivalent to 256 levels

  • * 1,648 mm when finisher tray and exit tray are extended.
  • Shown with optional equipment.
Long-edge feeding.
Only short-edge feeding can be used with A6 paper.
In a standard measurement environment. May vary depending on operating conditions and environment.
When starting the MFP via the power button. 29 seconds when starting via the main power switch.
Storage capacity depends on procurement and sourcing status.
Replacing the standard-equipped SSD with the optional BP-SD10 increases storage capacity to 512 GB.
Including protuberances.
Long-edge feeding of A4 sheets from 1st paper tray, using document glass, without Auto Colour Selection and Auto Colour mode, MFP in fully ready condition. May vary depending on operating conditions and environment.
Not available when using document glass.
Based on Sharp’s A4 standard chart, using document feeder, long-edge feeding, and one-sided scanning. Using factory default settings with Auto Colour Selection off. Scan speed will vary depending on the type of document and the scan settings.
Resolution will vary depending on the size of the scanned area.
Requires optional MX-EB20.
Colour/greyscale only.
Requires optional MX-EB19.
Requires Network Scanner Tool Lite.
Storage capacity will vary depending on the type of document and the scan settings.
Some features require optional equipment.
Requires optional BP-EB10.
Mac OS requires optional MX-PK13.
Based on Sharp’s standard chart with approx. 700 characters (A4 long-edge feeding) at standard resolution in Super G3 mode, 33,600 bps, JBIG compression.
  • Design and specifications are subject to change without prior notice.
  • Microsoft Teams, Windows, and Windows Server are trademarks of the Microsoft group of companies. AirPrint and Mac are trademarks of Apple Inc., registered in the US and other countries. Wi-Fi Protected Setup is a trademark of Wi-Fi Alliance®. PCL is a registered trademark of Hewlett-Packard Company. Adobe and PostScript are either registered trademarks or trademarks of Adobe in the US and/or other countries. All other brand names and product names may be trademarks or registered trademarks of their respective owners.
